Fixed-Focal-Length Cinema Lenses

• Focal length: 15 mm
• Maximum aperture: T1.8
• Frame: LPL
• Cover: large format (LF) / full format
• Minimum focus distance: 0.35 m (from the sensor)
• Front diameter: 156 mm
• Length (from the base plate): 197 mm
• Weight: 2.8 kg
• Horizontal field of view: 102° (LF Open Gate)
• Lens metadata: ARRI LDS-2 / Cooke /i

• Mount: LPL (LDS-2 / Cooke i metadata)
• Coverage: Large format (ALEXA LF / Mini LF)
• Focal length: 18 mm
• Aperture: T1.8 – T22
• Minimum focus distance: 0.35 m (from the sensor plane)
• Front diameter: 114 mm
• Length: 178 mm (from the frame)
• Weight: approx. 2.0 kg

• Focal length: 25 mm
• Maximum aperture: T1.8
• Frame: LPL
• Cover: large format (LF) / full format
• Minimum focus distance: 0.35 m (from the sensor)
• Front diameter: 114 mm
• Length (from the base plate): 178 mm
• Weight: 1.9 kg
• Horizontal field of view: 73° (LF Open Gate)
• Lens metadata: ARRI LDS-2 / Cooke /i

• Type: Large-format cinema fixed-focal-length lens
• Focal length: 35 mm
• Aperture: T1.8 – T22
• Mount: LPL (LDS-2 / Cooke i metadata)
• Cover: ARRI LF large format
• Minimum focusing distance: 0.35 m
• Front diameter: 114 mm
• Length from the mount: 178 mm
• Weight: 1.7 kg
• Horizontal field of view: 55.5° (LF Open Gate)

• Type: Large-format cinema fixed-focal-length lens
• Focal length: 58 mm
• Aperture: T1.8 – T22
• Mount: LPL (LDS-2 / Cooke i metadata)
• Minimum focus distance: 0.45 m (from the sensor plane)
• Front diameter: 114 mm
• Length: 178 mm (from the frame)
• Weight: 2.0 kg

Technical Specifications: DZO Vespid 50mm T2.1

● Type: Full-frame prime cinema lens
● Focal length: 50 mm
● Aperture: T2.1 to T22
● Image coverage: up to 46.5 mm (full frame / VistaVision)
● Available mounts: PL and EF (interchangeable mount)
● Minimum focus distance: 0.45 m
● Front diameter: 80 mm
● Filter thread: 77 mm
● Focus ring rotation: 270°
● Iris ring rotation: 70°
● Iris: 16 blades
● Standard cinema gears: 0.8 mod (focus and iris)
● Markings: meter or foot scales depending on version, markings on both sides
● Focus: internal (no rotation of the front lens)

• Focal length: 25 mm
• Opening: T2.1 through T22
• Cover: full frame (image circle 46.3 mm)
• Mount: interchangeable PL/EF (also E, F, MFT)
• Minimum focusing distance: 0.26 m
• Front diameter: 95 mm
• Focus rotation: 300°
• Length: 83.7 mm
• Weight: 0.82 kg (PL version)

• Type: fixed-focal-length cinema lens
• Focal length: 85 mm
• Opening: T2.1 – T22
• Cover: full-page
• Mount: Interchangeable PL / EF (also F, E, MFT)
• Minimum focus distance: 1.0 m
• Front diameter: 95 mm
• Weight: 0.88 kg

• Focal length: 18 mm
• Opening: T2.4 – T16
• Coverage: full format (99° field of view)
• Lenses: interchangeable E, RF, L, M (copy provided in E or RF)
• Front diameter: 82 mm
• Filter thread: M77 × 0.75
• Diaphragm: 9 blades
• Rotation: 160°, iris 78°
• Length: 109 mm
• Weight: approx. 688 g

• Frame: DJI DL
• Focal length: 24 mm
• Maximum aperture: f/2.8
• Shutter: Central (Leaf Shutter)
• Compatibility: Zenmuse X7, X9-6K, X9-8K Air, X9-8K, P1
• Construction: carbon fiber monocoque
• Dimensions: 55 × 62 × 71.2 mm
• Weight: 180 g

• Focal length: 50 mm
• Aperture: f/2.8
• Frame: DJI DL
• Type: fixed focal length (LS ASPH, central shutter)
• Construction: monocoque carbon-fiber hull
• Focus: motorized, camera-controlled (AF)
• Compatibility: Zenmuse X7, X9-8K, P1, Ronin 4D, Inspire 2, and 3

• Focal length: 25 mm
• Aperture: T2.1
• Mount: PL (Canon EF interchangeable lens kit)
• Cover: full frame / Vista Vision (image circle Ø46.5 mm)
• Minimum focus distance: 0.30 m
• Front diameter: 80 mm
• Filter thread: 77 mm
• Diaphragm blades: 16
• Length: approx. 99 mm
• Weight: approx. 950 g

• Type: fixed-focal-length cinema lens
• Focal length: 35 mm
• Aperture: T2.1
• Image circle: 46.5 mm (Full Frame / Vista Vision)
• Minimum focus distance: 0.46 m
• Focus rotation: 270°
• Filter: M77
• Rings: standard 0.8
• Mounts: PL / EF (interchangeable)
• Weight: approx. 962 g

• Mount: Canon EF
• Aspect Ratio: Full Frame / VistaVision (44.7 mm image circle)
• Focal length: 12 mm
• Opening: T2.9 – T22
• Field of view: 122°
• Optical design: 16 elements in 10 groups
• Minimum focus distance: 18 cm (from the sensor)
• Focus rotation: 270°, 0.8 MOD rings
• Diaphragm: 7 blades
• Filter thread: 95 mm (including 114 mm front ring)
• Length: 87 mm
• Weight: 675 g

• Frame: PL
• Aspect Ratio: Full Frame / VistaVision (44.7 mm image circle)
• Focal length: 12 mm
• Opening: T2.9 – T22
• Field of view: 122°
• Optical design: 16 elements in 10 groups
• Minimum focus distance: 18 cm (from the sensor)
• Focus rotation: 270°, 0.8 MOD rings
• Diaphragm: 7 blades
• Filter thread: 95 mm (including 114 mm front ring)
• Length: 87 mm
• Weight: 675 g

• Focal length: 12 mm
• Opening: T2.9 – T22
• Mount: PL (also available in EF, RF, E, and L)
• Aspect ratio: full frame / VistaVision (Alexa LF, Monstro)
• Distortion: virtually zero (Zero-D)
• Minimum focus distance: 0.18 m
• Front diameter: 95 mm (114 mm ring for matte box)
• Diaphragm: 7 blades
• Point rotation: 270°, toothed rings 0.8
• Weight: approx. 675 g

Technical Specifications

• Focal lengths: 21, 28, 35, 50, and 75 mm
• Aperture: T1.5 to T16 (fixed)
• Mount: Sony E (native)
• Coverage: full frame (43.2 mm image circle), Super 35, and APS-C
• Diaphragm: 16 blades
• Optics: aspheric, ED, and high-refractive-index elements; multi-layer coating
• Resolution: 8K-compatible
• Adjustment range: 210°
• Weight: approximately 390 to 470 g per lens
